- The control panel allows the operator to conveniently make adjustments for a precise application.
- Maximize ground coverage with two 30-gallon spray tanks and a 250 lb. hopper capacity.
- Reduce operator fatigue with rubber compression in the foot plate and a larger padded knee bolster.
- The flip up hopper provides easy access to the engine and battery for maintenance.
- Ride in style with larger wheels, improved hopper cover and knee bolster featuring Toro's bullhorn logo.
- The new design increases the balance and stability resulting in less turf tear up.
- Easy spot spraying with larger foot switch so the operator doesn't accidentally hit it. Operator can move the location to three different spots for convenience.
- Carry up to 100 lbs. of additional fertilizer with 2 fertilizer trays (50 lbs. per tray) to get the job done faster with less re-fill trips.
- Horizon360® Business Management Software. Work More Efficiently. Run More Profitably.
Specifications
| CARB Compliant | Not CARB Compliant |
|---|---|
| Drive System | HYDRO |
| Engine | Vanguard 23 hp |
| Engine Brand | Briggs and Stratton |
| Engine Displacement (cc) | 627 cc |
| Engine Horsepower | 23.0 hp |
| Frame | Stainless Steel |
| Fuel Capacity | 5 gal. / 18.9 L / 20 Qt. |
| Fuel Type | Gasoline |
| Ground Speed | Up to 10.0 mph / 16.0 kph |
| Hopper Capacity | 250 lbs |
| Product Type | Spreader/Sprayer |
| Product Use | Commercial |
| Recommended Oil Type | 10W50 |
| Spray Capacity (gallons) | 60 |
| Spray Wand | Standard, hand-held spray wand for spot spraying |
| Spray Width | 2 ft, 6 ft, 8 ft or 10 ft / 0.6 m, 1.8 m, 2.4 m or 3.0 m |
| Spreader Hopper Capacity (lbs) | 250 |
| Spreading Width | Up to 25 ft |
| Start Type | Electric |
| Tires | Drive Tires 24 in. x 12 in. - 12 in. / 60.9 cm x 30.4 cm - 30.4 cm; & Ribbed Front Tires 16 in. x 6.5 in. - 6 in. / 40.6 cm x 16.5 cm x 15.2 cm |
| Transaxle | HydroGear ZT5400 |
| Weight | 950 lbs / 431kg |
